acestep-cpp-comfyui

ComfyUI custom nodes that wrap acestep.cpp — a portable C++17 implementation of ACE-Step 1.5 music generation using GGML. Text + lyrics in, stereo 48 kHz audio out. Runs on CPU, CUDA, Metal, and Vulkan.

Features

  • Build the ace-lm and ace-synth binaries from source via the Acestep.cpp Builder node (no terminal required)
  • Download the required GGUF models directly from HuggingFace without leaving ComfyUI
  • Load the four GGUF model files required by acestep.cpp (LM, text encoder, DiT, VAE)
  • Load LoRA adapters from a dedicated Acestep.cpp LoRA Loader node
  • Configure advanced technical options via the Acestep.cpp Options node (output format, VAE tiling, batch size, debug flags)
  • Generate music from a caption and optional lyrics/metadata
  • Full control over generation parameters (turbo and SFT presets)
  • Cover mode, repaint mode, lego mode, and LoRA adapter support
  • All generation parameters aligned with the acestep.cpp request JSON reference
  • Connect AUDIO tensors from any LoadAudio node directly to the generator for source audio
  • Returns a ComfyUI AUDIO tensor, compatible with any audio preview or save node
  • Ready-to-use example workflows in workflow-examples/

Prerequisites

git and cmake must be on your system PATH before using the Builder node (or the manual build below). Everything else is handled inside ComfyUI.

# Debian/Ubuntu
apt install git cmake build-essential

# macOS (Homebrew)
brew install cmake

1 – Build acestep.cpp

Option A – Acestep.cpp Builder node (recommended)

After installing this custom node package, drop the Acestep.cpp Builder node onto your canvas and click Queue. It will:

  1. Clone https://github.com/audiohacking/acestep.cpp into <node_dir>/acestep.cpp
  2. Run git submodule update --init --recursive
  3. Configure with CMake (auto-detecting CUDA → Metal → CPU)
  4. Build ace-lm and ace-synth using all available CPU cores

The binaries land in <node_dir>/acestep.cpp/build/, which is where the Generate node looks first — no extra config needed.

Option B – Command line

Clone acestep.cpp inside the node directory so the Generate node finds the binaries automatically — no configuration required:

cd ComfyUI/custom_nodes/acestep-cpp-comfyui
git clone https://github.com/audiohacking/acestep.cpp
cd acestep.cpp
git submodule update --init
mkdir build && cd build

# Linux (NVIDIA GPU)
cmake .. -DGGML_CUDA=ON
# macOS (Metal auto-enabled)
cmake ..
# CPU with OpenBLAS
cmake .. -DGGML_BLAS=ON

cmake --build . --config Release -j$(nproc)

This produces ace-lm and ace-synth in <node_dir>/acestep.cpp/build/, which is where the Generate node already looks — no extra config needed.

2 – Download GGUF models

Option A – Acestep.cpp Model Downloader node (recommended)

After installing this custom node package, use the Acestep.cpp Model Downloader node inside ComfyUI. It downloads the required GGUFs from Serveurperso/ACE-Step-1.5-GGUF straight into your model folder. huggingface_hub must be available:

pip install huggingface_hub

Option B – Command line

pip install huggingface_hub[cli]   # installs the 'hf' CLI tool
./models.sh          # Q8_0 turbo essentials (~7.7 GB)

Pre-quantized GGUFs are available on Hugging Face.

Default models (placed in models/):

GGUF Role Size
acestep-5Hz-lm-4B-Q8_0.gguf LM (ace-lm) 4.2 GB
Qwen3-Embedding-0.6B-Q8_0.gguf Text encoder 748 MB
acestep-v15-turbo-Q8_0.gguf DiT 2.4 GB
vae-BF16.gguf VAE 322 MB

Installation

Fresh install

cd ComfyUI/custom_nodes
git clone https://github.com/audiohacking/acestep-cpp-comfyui

Restart ComfyUI. On startup the node will attempt to build the ace-lm and ace-synth binaries automatically if git and cmake are available. If the automatic build does not complete, use the Acestep.cpp Builder node inside ComfyUI — no manual file editing required.

Updating an existing installation

cd ComfyUI/custom_nodes/acestep-cpp-comfyui
git pull

Then restart ComfyUI so it picks up the new node code.

After updating: if your existing workflows show validation errors such as "Failed to convert an input value to a INT/FLOAT value", the workflow was saved with an older version of the node. Simply delete the Generate node from the canvas, re-add it from the node list, and re-connect its inputs — this resets the widget values to the current defaults and clears any stale empty-string placeholders.

Advanced Configuration

config.json is optional and only needed if you store binaries or models in non-standard locations.

Copy config.example.json to config.json in the node directory and set only the keys you need:

{
  "model_folders": [
    "/custom/path/to/models"
  ],
  "binary_paths": {
    "ace-lm": "/custom/path/to/build/ace-lm",
    "ace-synth": "/custom/path/to/build/ace-synth"
  }
}

model_folders – additional directories to scan for .gguf files, merged with ComfyUI's built-in text_encoders folder.

binary_paths – override the automatic binary search. The node already looks in your system PATH and <node_dir>/acestep.cpp/build/, so this is only needed for custom build locations.

Example Workflows

Ready-to-use workflow JSON files are in the workflow-examples/ directory. Drag one onto the ComfyUI canvas or load it via Load workflow.

File Description
acestep-cpp-text2music.json Basic text-to-music generation
acestep-cpp-lora.json Text-to-music with a LoRA adapter
acestep-cpp-reference-audio.json Cover mode using a source audio file
acestep-cpp-cover.json Cover/remix mode using a source audio file

Prerequisites: download the GGUF models (use the Model Downloader node) and build the binaries (use the Builder node) before running a generation workflow.

Node Reference

Acestep.cpp Builder

Clones audiohacking/acestep.cpp from GitHub and builds the ace-lm and ace-synth binaries using CMake. Requires git and cmake on the system PATH.

Inputs (required)

Name Default Description
clone_dir <node_dir>/acestep.cpp Directory to clone the repo into
backend auto CMake backend: auto (detects CUDA → Metal → CPU), cuda, metal, blas, cpu

Inputs (optional)

Name Default Description
force_rebuild false Remove the existing build/ directory and rebuild from scratch

Outputs

Name Type Description
build_log STRING Full cmake configure + build output

Tip: Run this node once to compile the binaries. The default clone_dir places them where the Generate node already searches, so no further configuration is needed.

Acestep.cpp Model Downloader

Downloads the required ACE-Step GGUF files from Serveurperso/ACE-Step-1.5-GGUF on HuggingFace into a local directory. Quant availability per model type mirrors the logic in models.sh.

Inputs (required)

Name Default Description
save_dir ComfyUI text_encoders folder Directory to save downloaded GGUF files
lm_size 4B LM model size: 4B, 1.7B, or 0.6B
quant Q8_0 Quantisation level (falls back to nearest valid quant for each model type)
dit_variant turbo DiT variant: turbo, sft, base, turbo-shift1, turbo-shift3, turbo-continuous

Inputs (optional)

Name Default Description
hf_token (empty) HuggingFace access token (not needed for public repos)
overwrite false Re-download even if the file already exists

Outputs

Name Type Description
downloaded_files STRING Summary of files downloaded / skipped

Tip: Run this node once to populate your model folder, then bypass/disable it and connect the Model Loader node to the same save_dir.

Acestep.cpp Model Loader

Selects the four GGUF model files and validates that they exist on disk.

Inputs (required)

Name Description
lm_model LM GGUF (e.g. acestep-5Hz-lm-4B-Q8_0.gguf)
text_encoder_model Text-encoder GGUF (e.g. Qwen3-Embedding-0.6B-Q8_0.gguf)
dit_model DiT GGUF (e.g. acestep-v15-turbo-Q8_0.gguf)
vae_model VAE GGUF (e.g. vae-BF16.gguf)

Outputs

Name Type Description
models ACESTEP_MODELS Model path bundle passed to the generator

Acestep.cpp LoRA Loader

Specify a LoRA adapter file and scale, ready to connect to the Generate node. Enter the full path to any .safetensors file or PEFT directory anywhere on your filesystem.

Inputs (required)

Name Description
lora_path Full filesystem path to the LoRA adapter file (.gguf or .safetensors)
lora_scale Adapter scale (default 1.0)

Outputs

Name Type Description
lora ACESTEP_LORA LoRA bundle passed to the generator

Acestep.cpp Options

Configures advanced technical parameters for generation. Connect to the Generate node's options input. All fields are optional — unset fields fall back to acestep.cpp defaults.

Inputs (all optional)

Name Default Description
output_format mp3 Output audio format: mp3 (smaller) or wav (lossless)
mp3_bitrate 128 MP3 bitrate in kbps (only used when output_format is mp3)
vae_chunk 256 VAE latent frames per tile — reduce to lower VRAM usage
vae_overlap 64 VAE overlap frames per side
lm_batch 1 Number of LM sequences to generate in parallel (each produces a different song)
dit_batch 1 Number of DiT variations per LM output (max 9, differ only in noise)
no_flash_attn false Disable flash attention in both ace-lm and ace-synth
lm_max_seq 8192 KV cache size for ace-lm in tokens
lm_no_fsm false Disable FSM constrained decoding in ace-lm

Outputs

Name Type Description
options ACESTEP_OPTIONS Options bundle passed to the generator

Acestep.cpp Generate

Runs ace-lm (LM) then ace-synth (DiT + VAE) and returns the generated audio. Optionally connect an Acestep.cpp Options node to control output format, batching, and VAE tiling.

Inputs (required)

Name Description
models Output of the Model Loader
caption Music style/description — fed to both the LM and DiT text encoder

Inputs (optional — lyrics and metadata)

Name Default Description
lyrics (empty) Song lyrics. Empty = LM generates. [Instrumental] = no vocals.
instrumental false Convenience toggle: sets lyrics to [Instrumental] when enabled and lyrics is empty
vocal_language (empty) BCP-47 language code (en, fr, ja, …). Empty = LM detects. unknown = explicit no-language signal.
duration 0.0 Duration in seconds; 0.0 lets the LM decide (clamped to [1, 600] s)
bpm 0 Beats per minute; 0 lets the LM decide
keyscale (empty) Key and scale, e.g. C major; leave empty for the LM to decide
timesignature (empty) Time signature numerator, e.g. 4 for 4/4; leave empty for the LM to decide

Inputs (optional — DiT flow-matching)

Name Default Description
inference_steps 8 DiT denoising steps (8 = turbo preset, 50 = SFT preset)
guidance_scale 0.0 CFG scale; 0.0 auto-resolves to 1.0 at runtime (disabled). Values > 1.0 on turbo models are overridden to 1.0.
shift 3.0 Flow-matching schedule shift (3.0 = turbo, 1.0 = SFT)
seed -1 Random seed; -1 picks one at random

Inputs (optional — LM sampling)

Name Default Description
lm_temperature 0.85 LM sampling temperature — lower = more deterministic
lm_cfg_scale 2.0 LM classifier-free guidance scale — 1.0 disables CFG
lm_top_p 0.9 LM nucleus (top-p) sampling cutoff — 1.0 disables
lm_top_k 0 LM top-k sampling — 0 disables
lm_negative_prompt (empty) Negative caption for LM CFG in phase 2
use_cot_caption true When enabled, the LM enriches the caption via CoT and the enriched version is fed to the DiT

Inputs (optional — source audio: cover / repaint / lego)

Name Default Description
src_audio (empty) Path to a WAV or MP3 source file (prefer src_audio_input instead)
audio_cover_strength 0.5 Fraction of DiT steps using the source audio as context: 0.0 = pure text-to-music, 1.0 = near-passthrough
repainting_start -1.0 Repaint region start in seconds (requires src_audio; -1 = inactive)
repainting_end -1.0 Repaint region end in seconds (requires src_audio; -1 = source duration)
lego (empty) Lego mode track name (e.g. guitar, drums; requires src_audio and the base model)

Inputs (optional — LoRA and node connections)

Name Default Description
lora_path (empty) Path to a DiT LoRA adapter (.safetensors or PEFT directory)
lora_scale 1.0 LoRA adapter scale
src_audio_input (not connected) AUDIO tensor for cover/repaint/lego — connect from a Load Audio node; overrides src_audio
lora (not connected) ACESTEP_LORA from the LoRA Loader node; overrides lora_path / lora_scale
options (not connected) ACESTEP_OPTIONS from the Options node; controls output format, batching, and VAE tiling

Outputs

Name Type Description
audio AUDIO Generated stereo 48 kHz audio

Generation Modes

The mode is determined automatically from the inputs, following the acestep.cpp request JSON reference:

Mode How to activate
Text-to-music lyrics="" (LM generates lyrics) or caption only
Instrumental lyrics="[Instrumental]" or enable the instrumental toggle
Cover Connect src_audio_input or set src_audio
Repaint Connect src_audio_input + set repainting_start and/or repainting_end
Lego Connect src_audio_input + set lego track name (base model required)

Quick Start Presets

Turbo (fast, 8 steps)

inference_steps = 8
guidance_scale  = 0.0   (auto → 1.0)
shift           = 3.0

SFT (higher quality, 50 steps)

inference_steps = 50
guidance_scale  = 1.0
shift           = 1.0

License

MIT — see LICENSE.
